SC311 WIFI Astronomy Camera IMX662 EAA 2.4G for Astronomical Planetary Photography

SKU: F9384A-
US$ 259.99
  • The SC311 is designed with Sony IMX662 color CMOS sensor, which uses advanced STARVIS 2 technology. It has the characteristics of no amp glow and very low readout noise, higher sensitivity to red and near infrared(NIR) light;
  • 2.4G WiFi technology let you can use 4 devices at the same time and share the fun of astronomy with your friends. Support Android and Apple systems, you can download them in the software store;
  • 10M effective transmission sensing distance allows you to get rid of the shackles of the data cable, it is easier to realize the fun of astronomy observation outdoors;
  • Built-in 2400mah lithium battery, it can support about 4 hours of continuous work, allowing you to have more time to focus on observations;
  • Connect to our SvbonyAstro a software application designed by ourselves. You can do observation on your phone or pad and save them to the SC311 built-in TF card, and then easily share to social media.

Reviews of SC311

In Stock Out Of Stock

Special offers and product promotions

SC311 WIFI Astronomy Camera/IMX662/EAA

The SVBONY SC311 is the first wifi camera we developed for astrophotography. It uses Sony IMX662 color CMOS chip and 2.4G wifi technology to enjoy the fun of sharing with multiple people and a clearer visual experience.

IMX662 Color CMOS Sensor

The SC311 is designed with Sony IMX662 color CMOS sensor, which uses advanced STARVIS 2 technology. It has the characteristics of no amp glow and very low readout noise, higher sensitivity to red and near infrared(NIR) light. It is especially suitable for EAA Astronomy.


WIFI Technology

2.4G WiFi technology let you can use 4 devices at the same time and share the fun of astronomy with your friends. Support Android and Apple systems, you can download them in the software store .


10M WIFI Distance

10M effective transmission sensing distance allows you to get rid of the shackles of the data cable, it is easier to realize the fun of astronomy observation outdoors.


Share the Joy of Observation with Friends

4h Standby Time

Built-in 2400mah lithium battery, it can support about 4 hours of continuous work, allowing you to have more time to focus on observations.

SvbonyAstro Software

Connect to SvbonyAstro, a software application designed by SVBONY. You can do observation on your phone or pad and save them to the SC311 built-in TF card, and then easily share share your fun through social media with just one click.  For Apple phones, please search for SvbonyAstro in the app store and install the app.


Removable Protective Glass

The removable protective glass(UV/IR CUT filter) design allows you to experience it in more ways, but it should be noted that you should try not to disassemble it to avoid dust entering and affecting the later shooting results. This removable UV/IR CUT filter design high transmittance of more than 96% in the visible light range of 400-700nm. If you want to shoot infrared or ultraviolet band, try to use the IR685, IR850 filter to achieve different shooting experience.

Built-in TF Card

Built-in 32GB TF card, you can save photos or video files to the TF card, it will not occupy the storage space of the mobile device.

1.25"/CS/C Adapter

Equipped with a 1.25-inch/CS/C adapter ring to meet your various needs. You can install filters or camera lenses without having to consider purchasing adapters separately.


Compatible with MK105

Used with MK105, you should get good results in planetary photography, solar and lunar photography.


 Application Scenario

Give it a try and start a new exploration with us, and what kind of photos will you get?


SKU  Model CMOS Sensor Classification Pixel size Resolution  USB Type
F9198A SV305 IMX290 color 2.9μm x 2.9μm  2MP USB 2.0
F9198B SV305 Pro  IMX290 color 2.9μm x 2.9μm  2MP USB3.0
F9198C SV305Pro AR  IMX290 color 2.9μm x 2.9μm  2MP USB3.0
F9198D SV305M Pro  IMX290 Monochrome  2.9μm x 2.9μm  2MP USB3.0
F9198L SV305C IMX662 color 2.9μm x 2.9μm  2.1MP USB2.0
F9198G SV905C IMX225 color 3.75μm x 3.75μm  1.2MP USB2.0
F9198H SV505C IMX464 color 2.9μm x 2.9μm  4.2MP USB3.0
F9198J SV705C IMX585 color 2.9μm x 2.9μm  8.3MP USB3.0
F9384A SC311 IMX662 color 2.9μm x 2.9μm  2.1MP Type-C
3 reviews

Write a review

Decent telescope camera

Arrived all right very fast.Satisfied excellent camera to connect to the phone

it is wireless and that it allows sharing what is observed in real time with at least four!

The SC311 is directed towards solar, moon and planets but focal length plays a large role, with a small censor, you would be better off using a smaller telescope to frame objects, not ideal if you only have a long focal length telescope, one way around this could be add a focal reducer which would increase field of view, this may be enough to frame larger objects.

Decent telescope camera

I loved that I didn’t have to worry much about looking at my phone, I just needed to follow the planet slowly. I did the same just taking pictures. In the end I separated the video frames and stacked the best frames to get a nice image. I have done this before with a DSLR and a barlow but this was much easier with this camera as everything saved on the camera memory and on my phone which is connected to my computer where I could grab the file and start working on it.

Specification

Model SC311
Sensor Model SONY IMX662
Total Pixels 2.1 Mega Pixels
Diagonal 6.44mm
Max Resolution 1920×1080
Pixel Size 2.9μm X 2.9μm
Chip Size 5.6mm×3.2mm
Exposure Range 0.02ms-5s
QE Peak ≈91%
ADC 12 bit
Adapter 1.25″/CS/C
Removable Protective Glass UV/IR CUT
Back Focal Length 12.5mm
Wifi module 2.4G,150Mbps
Storage TF Card, Max support 256G, come with 32G
USB Type Type-C
Build-In Battery 2400 mAh
Output Format Support Image jpg; Video MP4
Video support
Photograph support
Plan to take pictures support
Working Humidity 20%RH-80%RH
Storage Humidity 20%RH-95%RH
Operating Temperature -10°C~50°C
Storage Temperature -20°C~60°C
Net Weight 372g
Total Weight 400g

Features

1.Sony IMX662 color CMOS sensor
2.2.4G WiFi Technology, it can be connected to 4 devices at the same time
3.Built-in 2400mah lithium Battery & a 32GB TF ard
4. SvbonyAstro Software Application
5.Removable UV/IR CUT Filter Design
6.10M Effective Transmission Sensing Distance
7.Comes with 1.25″/CS/C Adapter

The Real Shot Image by SC311 WIFI Camera

Package Includes

 1 * Svbony SC311 Camera
 1 * WiFi Antenna
 1 * TF Card (32G)
 1 * USB Cable
 1 * 1.25” Extension tube
 1 * CS-C Lens adapter
 1 * 1.25”Dust cover
 1 * Cleaning cloth
 1 * User’s manual
