SV28( 20×60 80mm)+SV205 camera setup

SKU: F9308D-F9159D-W2787A-F9110A
-15% US$ 161.15
List Price: US$ 189.59

SV28( 20×60 80mm)+SV205 camera, connect the computer or your phone(need USB adapter).

Natural and Astronomy Observation.

In Stock Out Of Stock







0 reviews

Write a review

Model F9308D
Product Type Angled Spotting Scopes
Close Focus 8m
specification 20-60x80mm
Eyepiece diameter  21mm
Field of view 108-54 ft/1000yds
Prism Glass BAK4
Optical Coating MC
Eye Relief 16-14mm
Focal length 80mm
Water-resistant YES
FogProof: YES
Net Weight 1012g / 35.69oz
Dimensions 15.408x102x145mm

Model SV205
Sensor 1/3.2" CMOS Color
Sensor Model SONY IMX179
Pixel Size 1.4µmx1.4µm
Resolution 8M Pixels(3264*2448 YUV 15FPS/S)2592*1944 YUV 24FPS/S1920*1080 YUV 30FPS/S
USB Type USB3.0
Shutter Electronic Rolling Shutter
Exposure Time 15ms~500ms
Gain 0-120
Maximum Frame Rate 15FPS(3264*2448)30FPS(1920*1080)
ADC 10 bit
Interface Type Standard UVC protocol
Support OS Windows, Linux, Raspberry Pi, and Android
Support Telescope Telescope with 1.25'' diagonal base hole
Power Consumption 230mA@5V
Cable Length 1.8m

SV28( 20×60 80mm)and the SV205 camera provide sharp image quality.

1.It is nitrogen-filled, completely waterproof and fogproof. You could enjoy hunting, bird watching interest even in wet weather

2.BAK4 prism and FMC (Fully Multi-Coated) optics, increasing light transmission through the optical path to deliver crisp, high contrast images

3.Combined with the Porro Prism performance to give you crisp image with excellent color fidelity

4. Zoom eyepiece can give you a wide field of view for general viewing and detailed up close viewing when needed
